Loose Terminals Crimping Machine With Vibration Plate Feeding WPM-160
Loose Terminals Crimping Machine With Vibration Plate Feeding WPM-160 Loose Terminals Crimping Machine With Vibration Plate Feeding WPM-160 Loose Terminals Crimping Machine With Vibration Plate Feeding WPM-160
  • Loose Terminals Crimping Machine With Vibration Plate Feeding WPM-160

  • Model No: WPM-160

  • Loose Terminals Crimping Machine With Vibration Plate Feeding,Wire Loose Terminal Crimping Machine, Cable Lug Crimping Machine, Plastic Shell Terminal Crimping Machine
    Manual operation part
    Manually put the terminal into the vibration plate
    Manually put the wire into the terminal to be crimped
    Machine running part
    Automatically arrange and feed the terminals
    Automatically feed the terminal into the designated die
    (The feeding speed of regular terminals is 60~70 pcs per minute. The speed is 3000-4000 pcs per hour. Note: special terminals are excluded)When ready, start the crimp switch, and the pressing is completed automatically.
    Dimension 450*800*1200(MM)
    Voltage AC220V/50HZ
    Weight 160KG
    Consumed Power Motor: 250W, Working lamp: 60W,
    vibrating plate: 120W
    Crimping capacity 2.0T
    Stroke of the slide block 30MM
    Crimping times 120PCS/MIN
    Closing height 126MM
    Adjust the closing height of 10MM

  • Inquiry now
Detailed description

Loose Terminals Crimping Machine With Vibration Plate Feeding



This is a semi-automatic cable connector crimping machine. It is suitable for crimping loose piece terminals with vibration plate feeding. The operating speed is comparable to that of the chain terminals, saving labor and cost, and having more cost-effective advantages.


Features

Manual operation part

Manually put the terminal into the vibration plate

Manually put the wire into the terminal to be crimped

Machine running part

Automatically arrange and feed the terminals

Automatically feed the terminal into the designated die

(The feeding speed of regular terminals is 60~70 pcs per minute. The speed is 3000-4000 pcs per hour. Note: special terminals are excluded)When ready, start the crimp switch, and the pressing is completed automatically.

Dimension 450*800*1200(MM)

Voltage AC220V/50HZ

Weight 160KG

Consumed Power Motor: 250W, Working lamp: 60W,

vibrating plate: 120W

Crimping capacity 2.0T

Stroke of the slide block 30MM

Crimping times 120PCS/MIN

Closing height 126MM

Adjust the closing height of 10MM
Loose Terminals Crimping Machine With Vibration Plate Feeding, Wire Loose Terminal Crimping Machine, Cable Lug Crimping Machine, Plastic Shell Terminal Crimping Machine Loose Terminals Crimping Machine With Vibration Plate Feeding, Wire Loose Terminal Crimping Machine, Cable Lug Crimping Machine, Plastic Shell Terminal Crimping Machine Loose Terminals Crimping Machine With Vibration Plate Feeding, Wire Loose Terminal Crimping Machine, Cable Lug CrimpingLoose Terminals Crimping Machine With Vibration Plate Feeding, Wire Loose Terminal Crimping Machine, Cable Lug Crimping Machine, Plastic Shell Terminal Crimping MachineLoose Terminals Crimping Machine With Vibration Plate Feeding, Wire Loose Terminal Crimping Machine, Cable Lug Crimping Machine, Plastic Shell Terminal Crimping Machine
